KLZ2012MHR3R3HTD25

KLZ2012MHR3R3HTD25

Image is for reference,
please contact us to get the real picture

Part No :

KLZ2012MHR3R3HTD25

Manufacturer
TDK Corporation
Description
FIXED IND 3.3UH 500MA 260 MOHM
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Jul 25 - Jul 29 2025
DataSheet
KLZ2012MHR3R3HTD25 PDF
Availability
1275 pieces
Unit Price
$0.30000

Current price of KLZ2012MHR3R3HTD25 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

KLZ2012MHR3R3HTD25 Specifications
Type Description
Series:KLZ-HR
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Type:Multilayer
Material - Core:Ferrite
Inductance:3.3 µH
Tolerance:±20%
Current Rating (Amps):500 mA
Current - Saturation (Isat):350mA
Shielding:Shielded
DC Resistance (DCR):260mOhm
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:AEC-Q200
Operating Temperature:-55°C ~ 150°C
Inductance Frequency - Test:2 MHz
Features:Soft Termination
Mounting Type:Surface Mount
Package / Case:0805 (2012 Metric)
Supplier Device Package:0805 (2012 Metric)
Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max):0.057" (1.45mm)
  • Please confirm the specifications of the products when ordering.
  • MOQ means the minimum order quantity required to purchase each parts.
  • If you have special order instructions,please note it on the ordering pages.
  • The Pre-Shipment Inspection (PSI) will be applied.
  • You can email us to change the order details before shipment.
  • Orders cannot be canceled after shipping the packages.
  • TT in advance (bank transfer), Credit Card, PayPal can be chosen.
  • Cash transfer only. (Transfer with checks and bills are not accepted.)
  • Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
  • If you need the detailed invoice or tax ID,please email us.
  • FedEx, DHL, and UPS can be selected.
  • You can select whether to charge shipping fee by your shipping account or to charge by our side.
  • Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
  • The shopping cart will automatically calculate the shipping cost.
  • Delivery time: At the same day (Order deadline is 2pm, HK Time).
  • Delivery date: usually 2 to 7 working days.
  • It is unable to appoint a date of delivery.
  • Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)
Hot Products
HOT 744762218A

744762218A

FIXED IND 180NH 800MA 330 MOHM
HOT CC453232-3R9KL

CC453232-3R9KL

FIXED IND 3.9UH 700MA 240MOHM SM
HOT 1447427C
