Current price of ELJ-DA101JF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | DA |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Obsolete |
Type: | Wirewound |
Material - Core: | - |
Inductance: | 100 µH |
Tolerance: | ±5% |
Current Rating (Amps): | 70 mA |
Current - Saturation (Isat): | - |
Shielding: | Unshielded |
DC Resistance (DCR): | 13Ohm Max |
Q @ Freq: | 24 @ 796kHz |
Frequency - Self Resonant: | 7MHz |
Ratings: | - |
Operating Temperature: | -20°C ~ 85°C |
Inductance Frequency - Test: | 796 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | 1210 (3225 Metric) |
Supplier Device Package: | - |
Size / Dimension: | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
Height - Seated (Max): | 0.094" (2.40mm) |
