PM0603-56NJ

PM0603-56NJ

Image is for reference,
please contact us to get the real picture

Part No :

PM0603-56NJ

Manufacturer
J.W. Miller / Bourns
Description
FIXED IND 56NH 600MA 310MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Aug 16 - Aug 20 2025
DataSheet
PM0603-56NJ PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of PM0603-56NJ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PM0603-56NJ Specifications
Type Description
Series:PM0603
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Obsolete
Type:Wirewound
Material - Core:Ceramic
Inductance:56 nH
Tolerance:±5%
Current Rating (Amps):600 mA
Current - Saturation (Isat):-
Shielding:Unshielded
DC Resistance (DCR):310mOhm
Q @ Freq:40 @ 200MHz
Frequency - Self Resonant:1.9GHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:200 MHz
Features:-
Mounting Type:Surface Mount
Package / Case:0603 (1608 Metric)
Supplier Device Package:0603 (1608 Metric)
Size / Dimension:0.065" L x 0.041" W (1.65mm x 1.05mm)
Height - Seated (Max):0.047" (1.20mm)
