Type | Description |
---|---|
Series: | Automotive, AEC-Q100 |
Package: | Tube |
Part Status: | Active |
Technology: | Capacitive Coupling |
Number of Channels: | 2 |
Voltage - Isolation: | 5000Vrms |
Common Mode Transient Immunity (Min): | 45kV/µs |
Propagation Delay tpLH / tpHL (Max): | 60ns, 60ns |
Pulse Width Distortion (Max): | 5.6ns |
Rise / Fall Time (Typ): | 12ns, 12ns |
Current - Output High, Low: | 2A, 4A |
Current - Peak Output: | 4A |
Voltage - Forward (Vf) (Typ): | - |
Current - DC Forward (If) (Max): | - |
Voltage - Output Supply: | 6.5V ~ 24V |
Operating Temperature: | -40°C ~ 125°C |
Mounting Type: | Surface Mount |
Package / Case: | 14-SOIC (0.295", 7.50mm Width) |
Supplier Device Package: | 14-SOIC |
Approval Agency: | CQC, CSA, UR, VDE |
