HCPL-6650

HCPL-6650

Image is for reference,
please contact us to get the real picture

Part No :

HCPL-6650

Manufacturer
Broadcom
Description
OPTOISO 1.5KV OPEN COLL 16FLATPK
Catalog
Optoisolators - Logic Output
Shipped from
HK warehouse
Expected Shipping Date
Jul 01 - Jul 05 2025
DataSheet
HCPL-6650 PDF
Availability
37 pieces
Unit Price
$125.10000

Current price of HCPL-6650 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

HCPL-6650 Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Number of Channels:4
Inputs - Side 1/Side 2:4/0
Voltage - Isolation:1500VDC
Common Mode Transient Immunity (Min):1kV/µs
Input Type:DC
Output Type:Open Collector, Schottky Clamped
Current - Output / Channel:25 mA
Data Rate:10MBd
Propagation Delay tpLH / tpHL (Max):100ns, 100ns
Rise / Fall Time (Typ):35ns, 35ns
Voltage - Forward (Vf) (Typ):1.5V
Current - DC Forward (If) (Max):20mA
Voltage - Supply:4.5V ~ 5.5V
Operating Temperature:-55°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:16-Flatpack
Supplier Device Package:16-Flatpack
