B65813J0000R030

B65813J0000R030

Image is for reference,
please contact us to get the real picture

Part No :

B65813J0000R030

Manufacturer
TDK EPCOS
Description
FERRITE CORE RM 7.6UH N30 2PCS
Catalog
Ferrite Cores
Shipped from
HK warehouse
Expected Shipping Date
Jul 01 - Jul 05 2025
DataSheet
B65813J0000R030 PDF
Availability
0 pieces
Unit Price
$2.08003

Current price of B65813J0000R030 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

B65813J0000R030 Specifications
Type Description
Series:B65813
Package:Box
Part Status:Active
Core Type:RM
Supplier Device Package:RM 10
Material:N30
Diameter:-
Inductance Factor (Al):7.6 µH
Tolerance:-20%, +30%
Gap:Ungapped
Effective Permeability (µe):2720
Initial Permeability (µi):4300
Core Factor (ΣI/A) mm-1:0.45
Effective Length (le) mm:44
Effective Area (Ae) mm²:98
Minimum Core Cross Section (Amin) mm²:90
Effective Magnetic Volume (Ve) mm³:4310
Finish:Uncoated
Height:9.35mm
Length:28.50mm
Width:13.50mm
