NHD-0216K1Z-NS(RGB)-FBW-REV1

NHD-0216K1Z-NS(RGB)-FBW-REV1

Image is for reference,
please contact us to get the real picture

Part No :

NHD-0216K1Z-NS(RGB)-FBW-REV1

Manufacturer
Newhaven Display, Intl.
Description
LCD MOD 32DIG 16X2 TRANSMS R/G/B
Catalog
Display Modules - LCD, OLED Character and Numeric
Shipped from
HK warehouse
Expected Shipping Date
Jul 01 - Jul 05 2025
DataSheet
NHD-0216K1Z-NS(RGB)-FBW-REV1 PDF
Availability
1384 pieces
Unit Price
$15.58000

Current price of NHD-0216K1Z-NS(RGB)-FBW-REV1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

NHD-0216K1Z-NS(RGB)-FBW-REV1 Specifications
Type Description
Series:-
Package:Box
Part Status:Active
Number of Characters:32
Display Format:16 x 2
Character Format:5 x 8 Dots
Display Type:FSTN - Film Super-Twisted Nematic
Display Mode:Transmissive
Character Size:5.23mm H x 3.00mm W
Outline L x W x H:80.00mm x 36.00mm x 13.00mm
Viewing Area:64.50mm L x 16.40mm W
Backlight:LED - Red/Green/Blue
Voltage - Supply:4.7V ~ 5.5V
Dot Size:0.56mm W x 0.61mm H
Interface:Parallel
Controller Type:SPLC780D OR ST7066U
Operating Temperature:-20°C ~ 70°C
Text Color:Red/Green/Blue
Background Color:Black
