HDSP-0763

Image is for reference,
please contact us to get the real picture

Part No :: HDSP-0763

Manufacturer: Broadcom

Description: DISP 7SEG 0.29" OV/FL RED 8DIP

Catalog: Display Modules - LED Character and Numeric

Shipped from: HK warehouse

Expected Shipping Date: Jun 30 - Jul 04 2025

DataSheet: HDSP-0763 PDF

Availability: 0 pieces

Unit Price: ~~$59.22667~~

Current price of HDSP-0763 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

HDSP-0763 Specifications

Type	Description
Series:	HDSP-076x
Package:	Bulk
Part Status:	Active
Display Format:	-
Number of Characters:	+/-1 (overflow)
Size / Dimension:	0.531" H x 0.402" W x 0.169" D (13.50mm x 10.20mm x 4.30mm)
Digit/Alpha Size:	0.29" (7.37mm)
Display Type:	7-Segment
Common Pin:	Common Anode
Color:	Red
Voltage - Forward (Vf) (Typ):	1.75V
Current - Test:	10mA
Millicandela Rating:	0.06mcd ~ 1.17mcd
Wavelength - Peak:	635nm
Power Dissipation (Max):	573mW
Package / Case:	8-DIP (0.600", 15.20mm)

Please confirm the specifications of the products when ordering.
