Type | Description |
---|---|
Series: | PicoLEDâ„¢ |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Color: | Red, Green, Blue (RGB) |
Configuration: | Common Anode |
Lens Color: | White |
Lens Transparency: | Diffused |
Millicandela Rating: | 35mcd Red, 110mcd Green, 45mcd Blue |
Lens Style: | Rectangle with Flat Top |
Lens Size: | 1.00mm x 0.60mm |
Voltage - Forward (Vf) (Typ): | 2.1V Red, 3.1V Green, 3V Blue |
Current - Test: | 5mA Red, 5mA Green, 5mA Blue |
Viewing Angle: | - |
Mounting Type: | Surface Mount |
Wavelength - Dominant: | 624nm Red, 527nm Green, 470nm Blue |
Wavelength - Peak: | - |
Features: | - |
Package / Case: | 0404 (1010 Metric) |
Supplier Device Package: | PICOLED |
Size / Dimension: | 1.00mm L x 1.00mm W |
Height (Max): | 0.25mm |
