Type | Description |
---|---|
Series: | Xlamp® CXB1830 |
Package: | Tray |
Part Status: | Active |
Type: | Chip On Board (COB) |
Color: | White, Warm |
CCT (K): | 3500K 2-Step MacAdam Ellipse |
Wavelength: | - |
Configuration: | Square |
Luminous Flux @ Current/Temperature: | 3095lm (2990lm ~ 3200lm) |
Current - Test: | 800mA |
Temperature - Test: | 85°C |
Voltage - Forward (Vf) (Typ): | 36V |
Lumens/Watt @ Current - Test: | 107 lm/W |
Current - Max: | 1.4A |
CRI (Color Rendering Index): | 90 |
Viewing Angle: | 115° |
Features: | - |
Size / Dimension: | 17.85mm L x 17.85mm W |
Height: | 1.70mm |
Light Emitting Surface (LES): | 14.00mm Dia |
Lens Type: | Flat |
