Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of CXB1310-0000-000N0BN450E is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | Xlamp® CXB1310 |
Package: | Bulk |
Part Status: | Active |
Type: | Chip On Board (COB) |
Color: | White, Cool |
CCT (K): | 5000K 5-Step MacAdam Ellipse |
Wavelength: | - |
Configuration: | Square |
Luminous Flux @ Current/Temperature: | 1770lm (1710lm ~ 1830lm) |
Current - Test: | 350mA |
Temperature - Test: | 85°C |
Voltage - Forward (Vf) (Typ): | 36V |
Lumens/Watt @ Current - Test: | 140 lm/W |
Current - Max: | 700mA |
CRI (Color Rendering Index): | 70 |
Viewing Angle: | 115° |
Features: | - |
Size / Dimension: | 13.35mm L x 13.35mm W |
Height: | 1.55mm |
Light Emitting Surface (LES): | 6.00mm Dia |
Lens Type: | Flat |
