JSM1024D12

Image is for reference,
please contact us to get the real picture

Part No :: JSM1024D12

Manufacturer: XP Power

Description: DC DC CONVERTER +/-12V 10W

Catalog: DC DC Converters

Shipped from: HK warehouse

Expected Shipping Date: Aug 11 - Aug 15 2025

DataSheet: JSM1024D12 PDF

Availability: 1173 pieces

Unit Price: ~~$30.00000~~

Current price of JSM1024D12 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

JSM1024D12 Specifications

Type	Description
Series:	JSM10 (10W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	2
Voltage - Input (Min):	18V
Voltage - Input (Max):	36V
Voltage - Output 1:	12V
Voltage - Output 2:	-12V
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	416mA, 416mA
Power (Watts):	10 W
Voltage - Isolation:	1.5 kV
Applications:	ITE (Commercial)
Features:	SCP, UVLO
Operating Temperature:	-40°C ~ 100°C
Efficiency:	88%
Mounting Type:	Through Hole
Package / Case:	6-DIP Module, 5 Leads
Size / Dimension:	1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	62368-1

Please confirm the specifications of the products when ordering.
