Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of AM1/2S-0515SH30Z is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | AM1/2S-Z (0.5W) |
Package: | Tube |
Part Status: | Active |
Type: | Isolated Module |
Number of Outputs: | 1 |
Voltage - Input (Min): | 4.5V |
Voltage - Input (Max): | 5.5V |
Voltage - Output 1: | 15V |
Voltage - Output 2: | - |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 33mA |
Power (Watts): | 500 mW |
Voltage - Isolation: | 3 kV |
Applications: | ITE (Commercial) |
Features: | - |
Operating Temperature: | -40°C ~ 85°C |
Efficiency: | 77% |
Mounting Type: | Through Hole |
Package / Case: | 4-SIP Module |
Size / Dimension: | 0.46" L x 0.24" W x 0.40" H (11.7mm x 6.0mm x 9.7mm) |
Supplier Device Package: | - |
Control Features: | - |
Approval Agency: | CE |
Standard Number: | - |
