PYBJ15-Q24-S5-OD

Image is for reference,
please contact us to get the real picture

Part No :: PYBJ15-Q24-S5-OD

Manufacturer: CUI Inc.

Description: DC DC CONVERTER 5V 15W

Catalog: DC DC Converters

Shipped from: HK warehouse

Expected Shipping Date: Jul 28 - Aug 01 2025

DataSheet: PYBJ15-Q24-S5-OD PDF

Availability: 1814 pieces

Unit Price: ~~$28.91000~~

Current price of PYBJ15-Q24-S5-OD is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PYBJ15-Q24-S5-OD Specifications

Type	Description
Series:	PYBJ15 (15W)
Package:	Tray
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	9V
Voltage - Input (Max):	36V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	3A
Power (Watts):	15 W
Voltage - Isolation:	1.5 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off, OCP, OVP, SCP
Operating Temperature:	-40°C ~ 85°C (With Derating)
Efficiency:	88%
Mounting Type:	Through Hole
Package / Case:	14-DIP Module
Size / Dimension:	1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	EN
Standard Number:	55024; 55032 Class A

Please confirm the specifications of the products when ordering.
