Current price of TMV 2-2412SHI is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | TMV 2HI (2W) |
Package: | Tube |
Part Status: | Active |
Type: | Isolated Module |
Number of Outputs: | 1 |
Voltage - Input (Min): | 21.6V |
Voltage - Input (Max): | 26.4V |
Voltage - Output 1: | 12V |
Voltage - Output 2: | - |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 168mA |
Power (Watts): | 2 W |
Voltage - Isolation: | 5.2 kV |
Applications: | ITE (Commercial) |
Features: | SCP |
Operating Temperature: | -40°C ~ 85°C (With Derating) |
Efficiency: | 82% |
Mounting Type: | Through Hole |
Package / Case: | 7-SIP Module, 4 Leads |
Size / Dimension: | 0.77" L x 0.30" W x 0.40" H (19.5mm x 7.5mm x 10.2mm) |
Supplier Device Package: | - |
Control Features: | - |
Approval Agency: | - |
Standard Number: | - |
