Current price of AM2D-2424DH30Z is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | AM2D-Z (2W) |
Package: | Tube |
Part Status: | Active |
Type: | Isolated Module |
Number of Outputs: | 2 |
Voltage - Input (Min): | 21.6V |
Voltage - Input (Max): | 26.4V |
Voltage - Output 1: | 24V |
Voltage - Output 2: | -24V |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 42mA, 42mA |
Power (Watts): | 2 W |
Voltage - Isolation: | 3 kV |
Applications: | ITE (Commercial) |
Features: | - |
Operating Temperature: | -40°C ~ 85°C |
Efficiency: | 82% |
Mounting Type: | Through Hole |
Package / Case: | 7-SIP Module, 5 Leads |
Size / Dimension: | 0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm) |
Supplier Device Package: | - |
Control Features: | - |
Approval Agency: | CE |
Standard Number: | - |
