AZ983-1A-12DE

AZ983-1A-12DE

Image is for reference,
please contact us to get the real picture

Part No :

AZ983-1A-12DE

Manufacturer
American Zettler
Description
80A SUPER-ISO AUTO RELAY
Catalog
Automotive Relays
Shipped from
HK warehouse
Expected Shipping Date
Jul 19 - Jul 23 2025
DataSheet
AZ983-1A-12DE PDF
Availability
96 pieces
Unit Price
$2.55000

Current price of AZ983-1A-12DE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

AZ983-1A-12DE Specifications
Type Description
Series:-
Package:Tray
Part Status:Active
Coil Type:Non Latching
Coil Current:150 mA
Coil Voltage:12VDC
Contact Form:SPST-NO (1 Form A)
Contact Rating (Current):80 A
Switching Voltage:75VDC - Max
Must Operate Voltage:7.8 VDC
Must Release Voltage:1.2 VDC
Operate Time:7 ms
Release Time:5 ms
Features:Sealed - Fully
Mounting Type:Through Hole
Termination Style:PC Pin
Operating Temperature:-40°C ~ 85°C
