ADZS22105

ADZS22105

Image is for reference,
please contact us to get the real picture

Part No :

ADZS22105

Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 90A 5V
Catalog
Power Relays, Over 2 Amps
Shipped from
HK warehouse
Expected Shipping Date
Jul 31 - Aug 04 2025
DataSheet
ADZS22105 PDF
Availability
16 pieces
Unit Price
$22.38000

Current price of ADZS22105 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

ADZS22105 Specifications
Type Description
Series:ADZS
Package:Tray
Part Status:Active
Mounting Type:Chassis Mount
Coil Voltage:5VDC
Contact Form:SPST-NO (1 Form A)
Contact Rating (Current):90 A
Switching Voltage:276VAC - Max
Coil Current:600 mA
Coil Type:Latching, Dual Coil
Features:-
Termination Style:Screw Terminal
Seal Rating:-
Coil Insulation:-
Must Operate Voltage:3.5 VDC
Must Release Voltage:-
Operate Time:20 ms
Release Time:20 ms
Operating Temperature:-40°C ~ 85°C
Contact Material:Silver Tin Oxide (AgSnO)
Relay Type:General Purpose
