Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of HE2AN-AC120V is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | HE |
Package: | Bulk |
Part Status: | Active |
Mounting Type: | Chassis Mount |
Coil Voltage: | 120VAC |
Contact Form: | DPST-NO (2 Form A) |
Contact Rating (Current): | 25 A |
Switching Voltage: | 277VAC, 30VDC - Max |
Coil Current: | 22.1 mA |
Coil Type: | Non Latching |
Features: | - |
Termination Style: | Plug In, Quick Connect - 0.250" (6.3mm) |
Seal Rating: | - |
Coil Insulation: | - |
Must Operate Voltage: | 84 VAC |
Must Release Voltage: | 18 VAC |
Operate Time: | 30 ms |
Release Time: | 30 ms |
Operating Temperature: | -50°C ~ 55°C |
Contact Material: | Silver Tin Oxide (AgSnO) |
Relay Type: | General Purpose |
