Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of T90S1D12-110 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | T90 |
Package: | Bulk |
Part Status: | Obsolete |
Mounting Type: | Through Hole |
Coil Voltage: | 110VDC |
Contact Form: | SPST-NO (1 Form A) |
Contact Rating (Current): | 30 A |
Switching Voltage: | 240VAC, 28VDC - Max |
Coil Current: | 8 mA |
Coil Type: | Non Latching |
Features: | - |
Termination Style: | PC Pin |
Seal Rating: | Sealed - Fully |
Coil Insulation: | Class F |
Must Operate Voltage: | 82.5 VDC |
Must Release Voltage: | 11 VDC |
Operate Time: | 15 ms |
Release Time: | 15 ms |
Operating Temperature: | -55°C ~ 85°C |
Contact Material: | Silver Cadmium Oxide (AgCdO) |
Relay Type: | General Purpose |
