Current price of RM805012 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | RM, SCHRACK |
Package: | Bulk |
Part Status: | Obsolete |
Mounting Type: | Chassis Mount |
Coil Voltage: | 12VDC |
Contact Form: | DPDT (2 Form C) |
Contact Rating (Current): | 25 A |
Switching Voltage: | 400VAC - Max |
Coil Current: | 109 mA |
Coil Type: | Non Latching |
Features: | Mechanical Indicator |
Termination Style: | Quick Connect - 0.250" (6.3mm) |
Seal Rating: | - |
Coil Insulation: | - |
Must Operate Voltage: | 9 VDC |
Must Release Voltage: | 1.2 VDC |
Operate Time: | 15 ms |
Release Time: | 10 ms |
Operating Temperature: | -45°C ~ 65°C |
Contact Material: | Silver Cadmium Oxide (AgCdO) |
Relay Type: | General Purpose |
