Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of DIP05-1C90-51D is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | DIP |
Package: | Tube |
Part Status: | Active |
Mounting Type: | Through Hole |
Coil Voltage: | 5VDC |
Contact Form: | SPDT (1 Form C) |
Contact Rating (Current): | 250 mA |
Switching Voltage: | 175VAC, 175VDC - Max |
Coil Current: | 25 mA |
Coil Type: | Non Latching |
Features: | Diode |
Termination Style: | PC Pin |
Seal Rating: | - |
Must Operate Voltage: | 3.5 VDC |
Must Release Voltage: | 0.75 VDC |
Operate Time: | 0.7 ms |
Release Time: | 1.5 ms |
Operating Temperature: | -20°C ~ 70°C |
Contact Material: | - |
