Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of G6A-274P-ST15-US-DC9 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | G6A |
Package: | Tube |
Part Status: | Active |
Mounting Type: | Through Hole |
Coil Voltage: | 9VDC |
Contact Form: | DPDT (2 Form C) |
Contact Rating (Current): | 2 A |
Switching Voltage: | 250VAC, 220VDC - Max |
Coil Current: | 16.7 mA |
Coil Type: | Non Latching |
Features: | - |
Termination Style: | PC Pin |
Seal Rating: | - |
Coil Insulation: | - |
Must Operate Voltage: | 7.2 VDC |
Must Release Voltage: | 0.9 VDC |
Operate Time: | 5 ms |
Release Time: | 3 ms |
Operating Temperature: | -40°C ~ 70°C |
Contact Material: | Silver (Ag), Gold (Au) |
Relay Type: | General Purpose |
RELAY GEN PURPOSE DPDT 2A 9VDC
