Type | Description |
---|---|
Series: | RAZORBACK |
Package: | Bulk |
Part Status: | Active |
RF Family/Standard: | Cellular, Navigation, WiFi |
Frequency Group: | Wide Band |
Frequency (Center/Band): | 802MHz, 1.582GHz, 2.2GHz, 2.45GHz, 5.537GHz |
Frequency Range: | 644MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.71GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.925GHz |
Antenna Type: | Module |
Number of Bands: | 4 |
VSWR: | 2 |
Return Loss: | - |
Gain: | 4.6dBi, 4.9dBi, 6dBi, 6.6dBi |
Power - Max: | 45 W |
Features: | Cable - 5.18m, LNA |
Termination: | SMA Male (3), RP-SMA Male (1) |
Ingress Protection: | IP67 |
Mounting Type: | Adhesive |
Height (Max): | 3.644" (92.55mm) |
Applications: | Beidou, DSRC, Galileo, GLONASS, GPS, LTE, Wi-Fi |
