Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of MK15-B-2 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | MK15 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Molded Body |
Circuit: | SPST-NO |
Operate Range: | 10 ~ 15AT |
Release Range: | - |
Current - Switching: | 500mA (AC/DC) |
Voltage - Switching AC: | 180 V |
Voltage - Switching DC: | 180 V |
Power - Rated: | 10W |
Operate Time: | 0.5 ms |
Release Time: | 0.05 ms |
Mounting Type: | Surface Mount |
Termination Style: | Gull Wing |
Length - Overall: | 0.768" (19.50mm) |
Size - Body: | 0.630" L x 0.098" W x 0.098" H (16.00mm x 2.50mm x 2.50mm) |
Height Above Board: | 0.102" (2.60mm) |
Operating Temperature: | -40°C ~ 130°C |
Capacitance: | 0.3 pF |
Current - Carry: | 1A (AC/DC) |
