Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of MK06-5-B is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | MK06 |
Package: | Bulk |
Part Status: | Active |
Type: | Molded Body |
Circuit: | SPST-NO |
Operate Range: | 10 ~ 15AT |
Release Range: | - |
Current - Switching: | 400mA (AC/DC) |
Voltage - Switching AC: | 200 V |
Voltage - Switching DC: | 200 V |
Power - Rated: | 10W |
Operate Time: | 0.6 ms |
Release Time: | 0.05 ms |
Mounting Type: | Through Hole |
Termination Style: | PC Pin |
Length - Overall: | 0.563" (14.30mm) |
Size - Body: | 0.563" L x 0.110" W x 0.126" H (14.30mm x 2.80mm x 3.20mm) |
Height Above Board: | 0.126" (3.20mm) |
Operating Temperature: | -20°C ~ 85°C |
Capacitance: | 0.2 pF |
Current - Carry: | 500mA (AC/DC) |
