Type | Description |
---|---|
Series: | 77 |
Package: | Bulk |
Part Status: | Active |
Number of Positions: | 4 |
Index Stops: | Fixed |
Number of Decks: | 1 |
Number of Poles per Deck: | 2 |
Circuit per Deck: | DP4T |
Contact Timing: | Non-Shorting (BBM) |
Current Rating (Amps): | 50mA (AC), 200mA (DC) |
Voltage Rating - AC: | 115 V |
Voltage Rating - DC: | 28 V |
Actuator Type: | Flatted (3.17mm Dia) |
Actuator Length: | 7.98mm |
Angle of Throw: | 36° |
Contact Material: | Silver Cadmium Oxide (AgCdO) |
Contact Finish: | Gold |
Mounting Type: | Panel Mount, Through Hole |
Termination Style: | PC Pin |
Features: | Shaft and Panel Sealed |
Depth Behind Panel: | 4.57mm |
