Type | Description |
---|---|
Series: | TL6100 |
Package: | Tube |
Part Status: | Active |
Circuit: | SPST-NO |
Switch Function: | Off-Mom |
Contact Rating @ Voltage: | 0.05A @ 12VDC |
Actuator Type: | Standard |
Mounting Type: | Through Hole |
Actuator Height off PCB, Vertical: | 6.90mm |
Actuator Length, Right Angle: | - |
Actuator Orientation: | Top Actuated |
Termination Style: | PC Pin |
Outline: | 7.20mm x 7.20mm |
Illumination: | Non-Illuminated |
Illumination Type, Color: | - |
Illumination Voltage (Nominal): | - |
Operating Force: | 130gf |
Ingress Protection: | - |
Features: | Process Sealed |
Operating Temperature: | -40°C ~ 85°C |
