Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of TL3302AF260QJ is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | TL3302 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Circuit: | SPST-NO |
Switch Function: | Off-Mom |
Contact Rating @ Voltage: | 0.05A @ 12VDC |
Actuator Type: | Rectangular Button |
Mounting Type: | Surface Mount |
Actuator Height off PCB, Vertical: | 4.30mm |
Actuator Length, Right Angle: | - |
Actuator Orientation: | Top Actuated |
Termination Style: | J Lead |
Outline: | 6.00mm x 3.50mm |
Illumination: | Non-Illuminated |
Illumination Type, Color: | - |
Illumination Voltage (Nominal): | - |
Operating Force: | 260gf |
Ingress Protection: | - |
Features: | Tactile Feedback |
Operating Temperature: | -20°C ~ 70°C |
SWITCH TACTILE SPST-NO 0.05A 12V
