1760F

1760F

Image is for reference,
please contact us to get the real picture

Part No :

1760F

Manufacturer
Hammond Manufacturing
Description
TRANSFORMER TUBE GUITAR AMP
Catalog
Audio Transformers
Shipped from
HK warehouse
Expected Shipping Date
Aug 24 - Aug 28 2025
DataSheet
1760F PDF
Availability
6 pieces
Unit Price
$42.80000

Current price of 1760F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

1760F Specifications
Type Description
Series:1760
Package:Box
Part Status:Active
Turns Ratio - Primary:Secondary:29.19:1
Impedance - Primary (Ohms):6.95kCT
Impedance - Secondary (Ohms):4, 8, 16
DC Resistance (DCR) - Primary:120Ohm
DC Resistance (DCR) - Secondary:171mOhm, 245mOhm, 476mOhm
Transformer Type:Push-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range:70Hz ~ 15kHz
Frequency Response:±1dB
Voltage - Isolation:-
Insertion Loss:-
Return Loss:-
Power Level:15W
Operating Temperature:-
Approval Agency:-
Mounting Type:Chassis Mount
Size / Dimension:3.250" L x 1.687" W (82.55mm x 42.85mm)
Height - Seated (Max):2.058" (52.27mm)
Termination Style:Wire Leads
