1760H

Image is for reference,
please contact us to get the real picture

Part No :: 1760H

Manufacturer: Hammond Manufacturing

Description: TRANSFORMER TUBE GUITAR AMP

Catalog: Audio Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jul 02 - Jul 06 2025

DataSheet: 1760H PDF

Availability: 1 pieces

Unit Price: ~~$40.22000~~

Current price of 1760H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

1760H Specifications

Type	Description
Series:	1760
Package:	Box
Part Status:	Active
Turns Ratio - Primary:Secondary:	40.62:1, 28.72:1, 20.31:1
Impedance - Primary (Ohms):	6.6kCT
Impedance - Secondary (Ohms):	4, 8, 16
DC Resistance (DCR) - Primary:	347.8Ohm
DC Resistance (DCR) - Secondary:	686mOhm, 803mOhm, 1.157Ohm
Transformer Type:	Push-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range:	70Hz ~ 15kHz
Frequency Response:	±1dB
Voltage - Isolation:	-
Insertion Loss:	-
Return Loss:	-
Power Level:	20W
Operating Temperature:	-
Approval Agency:	-
Mounting Type:	Chassis Mount
Size / Dimension:	3.710" L x 2.400" W (94.23mm x 60.96mm)
Height - Seated (Max):	2.371" (60.22mm)
Termination Style:	Wire Leads

Please confirm the specifications of the products when ordering.
