14A-56-20

Image is for reference,
please contact us to get the real picture

Part No :: 14A-56-20

Manufacturer: Signal Transformer

Description: PWR XFMR LAMINATED 56VA TH

Catalog: Power Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jun 30 - Jul 04 2025

DataSheet: 14A-56-20 PDF

Availability: 101 pieces

Unit Price: ~~$17.10000~~

Current price of 14A-56-20 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

14A-56-20 Specifications

Type	Description
Series:	One-4-All™
Package:	Box
Part Status:	Active
Type:	Laminated Core
Voltage - Primary:	115V, 230V
Voltage - Secondary (Full Load):	Parallel 10V, Series 20V
Current - Output (Max):	Parallel 5.6A, Series 2.8A
Primary Winding(s):	Dual
Secondary Winding(s):	Dual
Center Tap:	No
Power - Max:	56VA
Mounting Type:	Through Hole
Termination Style:	PC Pin
Size / Dimension:	76.20mm L x 63.50mm W
Height - Seated (Max):	28.60mm
Voltage - Isolation:	4000Vrms
Weight:	1.7 lbs (771.1 g)

Please confirm the specifications of the products when ordering.
