36-4

36-4

Image is for reference,
please contact us to get the real picture

Part No :

36-4

Manufacturer
Signal Transformer
Description
PWR XFMR LAMINATED 144VA CHAS MT
Catalog
Power Transformers
Shipped from
HK warehouse
Expected Shipping Date
Aug 01 - Aug 05 2025
DataSheet
36-4 PDF
Availability
1 pieces
Unit Price
$65.66000

Current price of 36-4 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

36-4 Specifications
Type Description
Series:-
Package:Box
Part Status:Active
Type:Laminated Core
Voltage - Primary:105V, 115V, 125V
Voltage - Secondary (Full Load):Parallel 18V, Series 36V
Current - Output (Max):Parallel 8A, Series 4A
Primary Winding(s):Single, Multiple Taps
Secondary Winding(s):Dual
Center Tap:Yes
Power - Max:144VA
Mounting Type:Chassis Mount
Termination Style:Solder, Quick Connect
Size / Dimension:104.80mm L x 85.70mm W
Height - Seated (Max):87.30mm
Voltage - Isolation:1500Vrms
Weight:6.8 lbs (3.1 kg)
