Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of DMF-12-S is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | DMF |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.165" (4.20mm) |
Number of Positions: | 12 |
Number of Rows: | 2 |
Row Spacing - Mating: | 0.165" (4.20mm) |
Number of Positions Loaded: | All |
Style: | Board to Cable/Wire |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Locking Ramp |
Contact Length - Mating: | - |
Contact Length - Post: | 0.134" (3.40mm) |
Overall Contact Length: | - |
Insulation Height: | 0.504" (12.80mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Tin |
Contact Finish Thickness - Mating: | - |
Contact Finish - Post: | Tin |
Contact Material: | Brass |
Insulation Material: | Polyamide (PA66), Nylon 6/6 |
Features: | - |
Operating Temperature: | -25°C ~ 85°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-2 |
Insulation Color: | Natural |
Current Rating (Amps): | 7A |
Voltage Rating: | 250VAC |
