744894400082

Image is for reference,
please contact us to get the real picture

Part No :: 744894400082

Manufacturer: Würth Elektronik Midcom

Description: INDUCT ARRAY 2 COIL 820NH SMD

Catalog: Arrays, Signal Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jun 30 - Jul 04 2025

DataSheet: 744894400082 PDF

Availability: 0 pieces

Unit Price: ~~$1.45600~~

Current price of 744894400082 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

744894400082 Specifications

Type	Description
Series:	WE-TDC
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	820 nH
Inductance - Connected In Series:	3.28 µH
Tolerance:	±30%
Current Rating - Parallel:	3.7 A
Current Rating - Series:	1.85 A
Current Saturation - Parallel:	9.6 A
Current Saturation - Series:	4.8 A
DC Resistance (DCR) - Parallel:	20mOhm Max
DC Resistance (DCR) - Series:	-
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.315" L x 0.315" W (8.00mm x 8.00mm)
Height:	0.150" (3.80mm)

Please confirm the specifications of the products when ordering.
