ACPL-336J-000E

ACPL-336J-000E

Image is for reference,
please contact us to get the real picture

Part No :

ACPL-336J-000E

Manufacturer
Broadcom
Description
OPTOISO 5KV 1CH GATE DRIVER 16SO
Catalog
Isolators - Gate Drivers
Shipped from
HK warehouse
Expected Shipping Date
Jul 01 - Jul 05 2025
DataSheet
ACPL-336J-000E PDF
Availability
554 pieces
Unit Price
$7.24000

Current price of ACPL-336J-000E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

ACPL-336J-000E Specifications
Type Description
Series:-
Package:Bulk
Part Status:Active
Technology:Optical Coupling
Number of Channels:1
Voltage - Isolation:5000Vrms
Common Mode Transient Immunity (Min):30kV/µs
Propagation Delay tpLH / tpHL (Max):220ns, 250ns
Pulse Width Distortion (Max):120ns
Rise / Fall Time (Typ):80ns, 45ns
Current - Output High, Low:2A, 2A
Current - Peak Output:2.5A
Voltage - Forward (Vf) (Typ):1.55V
Current - DC Forward (If) (Max):20 mA
Voltage - Output Supply:15V ~ 30V
Operating Temperature:-40°C ~ 105°C
Mounting Type:Surface Mount
Package / Case:16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:16-SO
Approval Agency:CSA, IEC/EN/DIN, UR
