Type | Description |
---|---|
Series: | 10PM |
Package: | Bulk |
Part Status: | Active |
Type: | Hybrid |
Coil Type: | Bipolar |
Voltage - Rated: | 24VDC |
Current Rating (Amps): | 630 mA |
Steps per Revolution: | 200 |
Step Angle: | 1.8° |
Accuracy: | - |
Torque - Holding (oz-in / mNm): | 8.78 / 62 |
Size / Dimension: | Square - 0.984" x 0.984" (25.00mm x 25.00mm) |
NEMA Frame Size: | 10 |
Diameter - Shaft: | 0.197" (5.00mm) |
Length - Shaft and Bearing: | 0.394" (10.00mm) |
Mounting Hole Spacing: | 0.787" (20.00mm) |
Termination Style: | Connector |
Operating Temperature: | - |
Coil Resistance: | 5.8 Ohms |
Features: | Round Shaft |
